ONLINE EVENT HVDC switchgear: Gas-insulated Systems

The PROMOTioN team of WP15 got back together for a live demonstration of gas-insulated HVDC grid protection systems on Thursday the 21st January 2021. The demonstration was conducted as a virtual event.

The Horizon 2020 project PROMOTioN (PROgress on Meshed HVDC Offshore Transmission Networks) concluded in September 2020, but our partners are still building onto the research-foundation laid out in the project.
This full-day workshop on gas-insulated HVDC switchgear was conducted online and featured live technologie demos, presentations and discussions, drawing up to 175 participants. Below, you will find a summary of the programme, the full recording of the workshop in two parts as well as all presentations held that day. Additional material regarding gas insulated HVDC switchgear can be found under "Deliverables" on the PROMOTioN website. For further questions please contact the workshop organizer Uwe Riechert.

Full workshop recording, part 1, 9am-1pm (external link)

Full workshop recording, part 2, 1pm-5pm (external link)
All presentations & background material (.zip file)


WORKSHOP PROGRAMME, Thursday, 21st January 2021

09:00 Introduction PROMOTioN
Cornelis Plet, Consultant, DNV GL - HVDC Technologies

09:15 Introduction to the workshop & overview WP15: How to reduce the size of platforms with HVDC
Uwe Riechert, Hitachi ABB Power Grids, WP15 leader

Part 1: Technology and Di-electric Testing

09:25 HVDC GIS in Japan
Yoshimasa Sato, Toshiba Energy Systems & Solutions Corporation

09:45 Testing of HVDC GIS
Nadew Belda, KEMA Labs, Netherlands and Hong He, DNV-GL Netherlands

10:05 HVDC GIS Installation: How Does it Increase Technology Readiness?
Michael Gatzsche, Hitachi ABB Power Grids

10:25 HVDC GIL Prototype Installation Test
Martin Hallas, Technical University of Darmstadt

10:45 Discussion
Moderator: Michael Gatzsche

11:00 Break

Part 2: Application and Standardization
11:20 IEC TC17 Update
Motoharu Shiiki, Toshiba, Convener IEC TC 17 WG6

Design Considerations for DC-GIS Applications for HVDC Offshore Bipole Grid Connection
Systems of TenneT
Alex Alefragkis, TenneT

11:45 Application of and requirements on a DC GIS in a TSO
Frank Richter, 50Hertz Transmission

12:00 CIGRE JWG D1/B3.57: Di-electric Testing of Gas-insulated HVDC Systems
Prof. Dr.-Ing. Claus Neumann, Consultant

CIGRE JWG B1/B3/D1.79: Recommendations for dielectric testing of HVDC gas insulated system cable sealing ends
Cornelis Plet, Consultant, DNV GL - HVDC Technologies

12:40 Discussion
Moderator: Nadew Belda

13:00 – 14:00 Break

Part 3: Diagnostics and SF6 Alternatives
14:00 Alternative Partial Discharge Monitoring Techniques for HVDC GIS
Armando R. Mor, Luis Carlos Castro Heredia, Delft University, Netherlands

14:25 – 14:50 Alternatives gases for future SF6 free HVDC GIS - focus on PD behavior and detection
Caterina Toigo, Cong Thanh Vu, Alain Girodet, SuperGrid Institute, France

14:50 – 15:15 CIGRE WG D1.63: Progress on Partial discharge detection under DC voltage stress
Prof. Dr.-Ing. Ronald Plath, Technical University Berlin

15:15 Discussion
Moderator: Armando R. Mor

15:40 Workshop Summary
Uwe Riechert
